1300R010BN3HC Hydraulic Oil Filter Element

Hydraulic filter elements are used to remove contamination from a lube oil or hydraulic fluid system. AYATER hydraulic filters provide a high level of clean fluids to reduce operating costs and prevent failure.

Envíeconsulta→

1300R010BN3HC Hydraulic Oil Filter Element

product introduction

The hydraulic filters can be applied in many industries, such as the Pulp&Paper industry and the Hydropower industry.

“R” element type belongs to the low-pressure return line filter element.

It possesses a rhombic exoskeleton.

AYATER 1300R010BN3HC can fit the dimensions original machine.

1300R010BN3HC hydraulic filter element

Product Attribute	Specifications
Model Number	1300R010BN3HC
Filtration Material	Glass Fiber from HV Company
Application	Turbine Lube, Mineral Oil, Phosphate Ester
Seal Material	Viton O-Ring
Filter Rating	10µm
Filtration Efficiency	About 99%
Temperature Range	0-100
Flow Direction	Out/In
Total Height	483mm
Outside Diameter	143.5mm
Number of By-pass Valves	1.0

Related Series
1300R005BN3HC	1300R010BN3HC	1300R010BN4HC-B4-KE50	1300R010BN3HCV
1300R010ON	1300R010BN4HC	1300R010BN4HC-C-B4	1300R020BN4HC
1300R020V	1300R010BN4HC-V-B4-SKE25	1300R020ON	1300R005ON
